Memory Set and Call Out
The charger can store up to 10 di erent charge pro les for your convenience, and
the stored pro les can be recalled quickly without having to go through the setup
process. When you are willing to alter the parameter value in the program, press
START/ENTER to make it blink then change the value with INC or DEC. The value will
be stored by pressing START/ENTER once.
Note: All following screen are taking 2S(7.4V) LiPo battery for example.
Enter the battery memory program: 10 Di erent
charge pro les can be stored.
START/ENTER button
Set the battery type:
(LiPo/LiHV/LiFe/LiIon/NiMH/NiCd/Pb).
◄DEC INC ►
Set the voltage and number of cells (2S-4S)
◄DEC INC ►
Set the charge current (0.1-5.0A)
◄DEC INC ►
Set the terminal voltage (4.18 -4.25V):
◄DEC INC ►
Press ENTER to save program:
START/ENTER button.
[BATT MEMORY 1]
ENTER SET ->
BATT TYPE
LiPo
BATT VOLTS
7.4V ( 2S )
CHARGE CURRENT
4.9A
TVC = YOU R RISK
4.20V
SAVE PROGRAM
ENTER
