HITEC X2 AC Plus - Page 10

18 19
Lithium Battery Program [LiP0/LiHV/LiFe/Lilon cont.]
You are now ready to begin charging. Press and hold the
ENTER/Start ► button until you see “BATTERY CHECK.”
followed by the “CONFIRM (ENTER) / CANCEL(STOP)“
screen. This screen displays the number of cells you set up
as ”R” and the number of cells detected by the processor as “S”. If both numbers
are identical, you may press and hold the ENTER/Start ► button to conrm and
begin charging. If these numbers do not match, press the BATT/PROG Stop ■
button to return to the previous screen and carefully check the number of cells
of the battery pack before proceeding.
DURING CHARGING/DISCHARGING, THE BATTERY SHOULD BE PLACED
INSIDE A FIRE PROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE
AWAY FROM OTHER COMBUSTIBLE OBJECTS.
Once charging has commenced, the charger will display
the following real-time information: battery type/cell
count, charging current, battery voltage, charging time and charged capacity.
If you are using a balance adaptor during charging,
you may press the + button to view the voltage of each
individual cell. You can also view a variety of other information as detailed on
page 13.
Once the battery is fully charged the screen will read “FINISHED” and the charger
will emit a chiming sound. Press the ■ button to stop charging. You may also
press the ■ button at any time during the charging process to stop charging.
Lithium Balance Charge Mode:
This function is for balancing the voltage of individual Lithium-polymer battery
cells while charging. In order to use the Balance Mode, the battery must have a
balance lead. Charging in this mode is dierent from the normal modes because
the built-in processor monitors the voltage of each individual cell and controls
the discharge of each individual cell in order to equalize the voltage. Use of
a balance adaptor with any battery that has a balance lead will improve the
performance and lifespan of your battery.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
Lithium Battery Program [LiP0/LiHV/LiFe/Lilon cont.]
See page 12 for the appropriate charging connections setup for this operation.
First, select the correct battery type by following the
instructions on page 16. Once you have set the correct
battery type, press the ► button once to enter the charge mode and battery
settings screen, use the INC. – or DEC + to select “BALANCE” mode. Press the ►
button again and the amp rate value will begin ashing. Use the + or ▬ buttons
to adjust the value to the desired rate. Follow the instructions provided with
your battery when setting the charge amperage rate.
Press the ► button again and the voltage value will begin ashing. Use the +
or ▬ buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
You are now ready to begin charging. Press and hold the
ENTER/Start ► button until you see “BATTERY CHECK.”
followed by the “CONFIRM (ENTER) / CANCEL(STOP)“
screen. This screen displays the number of cells you set up
as ”R” and the number of cells detected by the processor as “S”. If both numbers
are identical, you may press and hold the ENTER/Start ► button to conrm and
begin charging. If these numbers do not match, press the BATT/PROG Stop ■
button to return to the previous screen and carefully check the number of cells
of the battery pack before proceeding.
DURING CHARGING/DISCHARGING, THE BATTERY SHOULD BE PLACED
INSIDE A FIRE PROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE
AWAY FROM OTHER COMBUSTIBLE OBJECTS.
Once charging has commenced, the charger will display
the following real-time information: battery type/cell
count, charging current, battery voltage, charging time and charged capacity.
To view the voltage of each individual cell charging, press the + button. You can
also view a variety of other information as detailed on page 12.
Once the battery is fully charged the screen will read
“FINISHED” and the charger will emit a chiming sound.
Press the ■ button to stop charging. You may also press the ■ button at any time
during the charging process to stop charging.
Warning
R:3SE R S:3SER
CANCEL(STOP)
LiPo BALANCE
2.7A 11.1V (3S)
R:3SE R S:3SER
CONFIRM(ENTER)
Caution
LP3s 2.7A 11.88V
CHG 005:39 00256
4.07 4.06 4.11V
0.00 0.00 0.00V
R:3SE R S:3SER
CANCEL(STOP)
R:3SE R S:3SER
CONFIRM(ENTER)
Caution
LP3s 2.7A 11.88V
BAL 005:39 00256
4.07 4.06 4.11V
0.00 0.00 0.00V
