HITEC X2 AC Plus User Manual

2 3
Congratulations on purchasing your new X2 AC Plus Charger! This latest addition
to our innovative charger line oers expanded capacity and compatibility in
a portable and compact package. With dual inputs aording exible battery
charging at home and in the eld, the X2 AC Plus also boasts Hitec’s innovative
power distribution mode which allows you to eciently assign output power
based on individual battery requirements. Capable of charging all battery
chemistries (including the new generation LiHV), this powerhouse has a built-
in 10-amp power supply, internal balancing circuits and 10 dierent charge/
discharge proles. In addition, you may utilize your smartphone for remote
control via our optional WiFi module.
As with all Hitec products, please read the OPERATING INSTRUCTIONS, WARNING
and SAFETY NOTES in their entirety before you attempt to use your new product.
THE CHARGING AND DISCHARGING OF RC HOBBY BATTERIES CAN BE
DANGEROUS. FAILURE TO FOLLOW THESE EXPLICIT WARNINGS CAN
RESULT IN PROPERTY DAMAGE AND/OR LOSS OF LIFE.
A NEVER LEAVE YOUR CHARGER UNATTENDED WHILE IN OPERATION.
A NEVER CHARGE ON OR AROUND COMBUSTIBLE MATERIALS.
A NEVER CHARGE A DAMAGED BATTERY PACK.
A LOW COST, NO-NAME BATTERY PACKS POSE THE MOST DANGER. WE
RECOMMEND YOU ONLY USE BATTERY PACKS THAT ARE SOLD AND
WARRANTIED BY A REPUTABLE COMPANY.
A IT IS HIGHLY RECOMMENDED THAT YOU UTILIZE A SAFETY DEVICE SUCH
AS A STEEL CASE OR LIPO SACK™ WHILE CHARGING LITHIUM CHEMISTRY
BATTERIES.
A IT IS HIGHLY RECOMMENDED THAT YOU KEEP AN OPERABLE “CLASS A” FIRE
EXTINGUISHER IN THE CHARGING AREA.
FAILURE TO FOLLOW THESE WARNINGS CAN BE CONSIDERED
NEGLIGENCE BY THE OPERATOR AND MAY NEGATE ANY CLAIMS
FOR DAMAGES INCURRED
.
Hitec RCD USA will not be held responsible for any damages or injuries that may
occur by persons who fail to follow these warnings or who fail to properly follow
the instructions in this manual.
Table of Contents:
Introduction..................................................................................................................................03
Warning and Safety Notes.....................................................................................................04
Product Layout............................................................................................................................08
Specications................................................................................................................................09
Features..........................................................................................................................................10
Battery & Power Supply Connections..............................................................................12
Power Distribution....................................................................................................................13
Operation.......................................................................................................................................14
Program Flow Chart..................................................................................................................15
Charger Operation....................................................................................................................16
Lithium Battery Program [LiP0/LiHV/LiFe/Lilon]..................................................................17
NiMh/NiCd Battery Program.................................................................................................25
Pb Lead-Acid Battery Program............................................................................................29
Battery Meter...............................................................................................................................32
Battery Resistance Meter........................................................................................................33
Memory Preset - Data Store/Load......................................................................................34
Advanced System Set Up........................................................................................................36
Warning and Error Messages................................................................................................38
Using the Charge Control Software [CHARGE MASTER]..................................................39
Recommended Accessory......................................................................................................39
Commonly Used Terms............................................................................................................40
Conformity Declarations.........................................................................................................41
Disposal and Prop 65 Warning............................................................................................42
Warranty and Service...............................................................................................................42
Warning
Table of Contents Introduction
Warning

HITEC X2 AC Plus Specifications

General

Brand	HITEC
Model	X2 AC Plus
Category	Battery Charger
Language	English
