NiCD/NiMH Battery Program [cont.]
Once Re-Peak process has begun, the charger will
display the following real-time information: battery type,
charging current, battery voltage, elapsed time and charged capacity.
Once the Re-Peak process has completed, the screen will read “END: RE-PEAK”
and the charger will emit a chiming sound. The X2AC+ will display the charge/
discharge capacity for each cycle. Using the + and - buttons, you can scroll
through this data for each cycle.
NiCD/NiMH Cycle Mode:
The X2AC+ makes cycling of NiCD/NiMH batteries easy. The process of
discharging and recharging (cycling) can be achieved automatically with one
simple step and will improve the performance of NiCD/NiMH batteries. We
strongly recommend cycling any battery that has been discharged and stored
for a period of time. This will increase battery life and improve performance.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
FOR CYCLING, THE X2AC+ USES THE CHARGE/DISCHARGE AMPERAGE
AND VOLTAGE SETTINGS ENTERED IN THE CHARGE AND DISCHARGE
MODES SEE PAGE 16.
After selecting the correct battery type, use the + or ▬
buttons to select to the “CYCLE” mode. The Cycle Mode gives
you two cycling options: “DCHG>CHG” or “CHG>DCHG“. The “DCHG>CHG” option
will rst discharge the battery and then charge the battery.
The “CHG>DCHG” option will rst charge the battery and
then discharge the battery. If this screen does not currently
show the cycling option you desire, press the ► button once and this setting will
begin ashing. Use the + or ▬ buttons to change this setting.
Pressing the ► button again will cause the number of cycles option to begin
ashing. Use the + or ▬ buttons to change this to the number of cycles you
want the X2AC+ to run. The X2AC+ can cycle the battery a maximum of 5 times
consecutively.
Press and hold the ► button and cycling will begin.
NiCD/NiMH Battery Program [cont.]
Once cycling has commenced, the charger will display the
following real-time information: battery type, charging/
discharging current, battery voltage, charging time and charged capacity. You will
also see “D>C“ or “C>D“. This will indicate which cycling order you have chosen.
Either “D“ or “C“ will be ashing. This ashing indicates which part of the cycle is
currently being executed.
Once the cycling process is complete, the screen will read “END: CYCLE” and the
charger will emit a chiming sound. The X2AC+ will display the charge/discharge
capacity for each cycle. Using the + and ▬ buttons, you can scroll through this data
for each cycle.
Additional NiCD/NiMH Process Information:
During the NiMH/NiCd battery charging/discharging process the X2AC+ can
display a variety of information, using the + or ▬ buttons you can also view the
following information:
Delta Peak Input Voltage
sensitivity setting
External*/ internal Temperature
temperatures cut-o
Safety timer Capacity cut-
setting o setting
*Requires optional temperature sensor. (Part#: 44159)
Pb (Lead-Acid):
This program is only suitable for charging Pb (lead-acid)
batteries with nominal voltages of 2 to 20V. A Pb (lead-
acid) battery is signicantly dierent from NiCD/NiMH batteries. Pb batteries can
only deliver current lower in comparison to their capacity. The same restriction
applies to the charging process. Consequently, the optimum charge current
can only be 1/10 of the capacity. A Pb battery cannot be used for fast charging.
Please follow the instructions provided by the battery manufacturer.
The X2AC+ oers the following Pb charge modes: Charge and Discharge.
Warning
NiMH 1.3A 10.42V
RPC 004:04 00686
Note
NiMH CYCLE
DCHG > CHG 2
NiMH CYCLE
CHG > DCHG 5
NiMH 0.5A 9.6V
D > C 00086
NiMH Sensitivity
D.Peak 4mV/CELL
In Power Voltage
12.56V
Ext. Temp ----
Int. Temp 37
.
C
Temp Cut-off
50
.
C
Safety Time
ON 200min
Capacity Cut-Off
ON 5000mAh
BATT/PROGRAM
Pb BATT
Pb Lead-Acid Battery Program
