NiCD/NiMH Battery Program [cont.]
NiCD/NiMH Auto Charge Mode:
In this mode, the charger automatically detects the connected NiMH or NiCD
battery and determines the proper full charge and cuto thresholds. Setting the
upper charge current limit for safe levels based on your battery specications
will ensure safe charging of your specic battery. If you are unsure of the
maximum allowable charge rates, set the charger to a maximum of 1C (battery
mAh/1000, i.e., 2500mAh = 2.5A).
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
After selecting the correct battery type, use the + or ▬
buttons to change the charge mode to the “Auto CHARGE”
setting.
Press the ► button and the amp rate value will begin ashing. Use the + or ▬
buttons to adjust the value to the desired rate. Follow the instructions provided with
your battery when setting the upper charge amperage rate.
Press and hold the ► button to begin charging.
Once charging has commenced, the charger will display
the following real-time information: battery type, charging
current, battery voltage, charging time and charged capacity.
Once the battery is fully charged, the screen will read “END: FINISHED” and the
charger will emit a chiming sound. You can press the ■ button at any time during the
charging process to stop charging.
NiCD/NiMH Discharge Mode:
BEFORE YOU BEGIN DISCHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
After selecting the correct battery type, use the + or ▬
buttons to select to the “DISCHARGE” mode. Press the ►
button and the amp rate value will begin ashing. Use the + or ▬ buttons to adjust
the value to the desired discharge rate. Press the ► button again and the voltage
cuto will begin to ash. Use the + or ▬ buttons to adjust the value to the desired rate.
NiCD/NiMH Battery Program [cont.]
Follow the instructions provided with your battery when setting the voltage cuto.
The X2AC+ will stop discharging when the battery has reached the preset voltage
cuto.
Press and hold the ► button to begin discharging. Once
discharging has commenced, the charger will display
the following real-time information: battery type, discharging current, battery
voltage, discharging time and discharged capacity.
When discharging is complete, the screen will read “END:
CUTOFF-VOL” and the charger will emit a chiming sound.
The charger will display the elapsed time, end voltage and number of mAh
discharged.
You can press the ■ button at any time during the charging process to stop the
discharge process.
NiCD/NiMH Re-Peak Mode:
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
Applicable to NiMH and NiCD batteries only, in re-peak mode the charger can
peak charge the battery once, twice, or three times in a row automatically. This
process is good for conrming the battery is fully charged and for verifying how
well the battery can accept a fast charge. A ve-minute cool-down delay occurs
after each re-peak charge.
IN REPEAK MODE, THE X2AC+ USES THE CHARGE AMPERAGE AND
VOLTAGE SETTINGS ENTERED IN CHARGE MODE SEE PAGE 16.
After selecting the correct battery type, use the + or ▬
buttons to select to the “RE-PEAK” mode. Press the ►
button and Re-peak cycle number 1 begins to ash on the screen. Use the + or
▬ buttons the dial once will allow you to scroll through and set up to 3 total cycles.
Press the ► button to begin the re-peak process.
Warning
NiMH 1.3A 10.42V
AUT 002:22 00106
[TIME: 00:04:04]
9.6V 00640mAh
NiMH Auto CHARGE
CURRENT 1.3A
NiMH 1.3A 5.42V
AUT 002:22 00106
Warning
NiMH DISCHARGE
1.3A CUT:9.6V
Warning
Note
NiMH RE-PEAK
2
