Lithium Battery Program [LiP0/LiHV/LiFe/Lilon cont.]
DURING CHARGING/DISCHARGING, THE BATTERY SHOULD BE PLACED
INSIDE A FIRE PROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE
AWAY FROM OTHER COMBUSTIBLE OBJECTS.
Once charging has commenced, the charger will display
the following real-time information: battery type/cell
count, charging current, battery voltage, charging time and charged capacity.
If you are using a balance adaptor during charging,
you may press the + button to view the voltage of each
individual cell. You can also view a variety of other information as detailed on
page 13.
Once the battery has reached storage level the screen will read “FINISHED” and
the charger will emit a chiming sound. Press the ■ button to stop charging. You
may also press the ■ button at any time during the charging process to stop
charging.
Additional Lithium Battery Process Information:
During the Lithium battery charging/discharging process the X2AC+ can display
a variety of information. Pressing the + button allows you to see the following:
Voltage of each cell.
API1Charge capacity percentage and average cell voltage.
Pressing the ▬ button will display this information.
Final voltage setting Input voltage
Internal/external Cut-o
temperature* temperature
Safety timer settings Capacity cut
o settings
*Requires optional temperature sensor. (Part#: 44159)
NiCD/NiMH Battery Program
NiCD/NiMH:
This program is only suitable for charging/discharging NiCD/NiMH batteries. The
X2AC+ oers the following NiCD/NiMH charge modes: Charge, Auto Charge,
Discharge, Re-Peak and Cycle.
Selecting the Battery Type:
N1After powering on the X2AC+, press the ■ button repeatedly until you reach
the appropriate program for the battery type you wish to charge. For this example
we have chosen the “NiMH BATT“ or “NiCd BATT”program. Now press the ►
button to enter the desired program.
NiCD/NiMH Charge Mode:
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 0207.
After selecting the correct battery type, if the screen does not read “CHARGE”,
use the + or ▬ buttons to change it to the “CHARGE” mode.
Press the ► button and the amp rate value will begin
ashing. Use the + or ▬ buttons to adjust the value to the
desired rate. Follow the instructions provided with your battery when setting the
amperage rate.
Press and hold the ► button to begin charging.
Once charging has commenced, the charger will display
the following real-time information: battery type,
charging current, battery voltage, charging time and charged capacity. Once
the battery is fully charged, the screen will read “END: FINISH” and the charger
will emit a chiming sound. You can press the ■ button at any time during the
charging process to stop charging.
Caution
4.07 4.06 4.11V
0.00 0.00 0.00V
LP3s 2.7A 11.88V
DCH 005:39 00256
4.07 4.06 4.11V
0.00 0.00 0.00V
Fuel = 90%
Cell = 4.10V
End Voltage
12.6V(3S)
In Power Voltage
12.56V
Ext. Temp ----
Int. Temp 37
.
C
Temp Cut-off
50
.
C
Ext. Temp ----
Int. Temp 37
.
C
Temp Cut-off
50
.
C
Warning
NiMH CHARGE
CURRENT 1.3A
NiMH 1.3A 5.42V
CHG 002:22 00106
