HITEC X2 AC Plus - Page 12

22 23
Lithium Battery Program [LiP0/LiHV/LiFe/Lilon cont.]
Press the ► button again and the voltage value will begin ashing. Use the +
or ▬ buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
You are now ready to begin charging. Press and hold the
ENTER/Start ► button until you see “BATTERY CHECK.”
followed by the “CONFIRM (ENTER) / CANCEL(STOP)“
screen. This screen displays the number of cells you set up
as ”R” and the number of cells detected by the processor as “S”. If both numbers
are identical, you may press and hold the ENTER/Start ► button to conrm and
begin charging. If these numbers do not match, press the BATT/PROG Stop ■
button to return to the previous screen and carefully check the number of cells
of the battery pack before proceeding.
DURING CHARGING/DISCHARGING, THE BATTERY SHOULD BE PLACED
INSIDE A FIRE PROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE
AWAY FROM OTHER COMBUSTIBLE OBJECTS.
Once charging has commenced, the charger will display
the following real-time information: battery type/cell
count, charging current, battery voltage, charging time and charged capacity.
If you are using a balance adaptor during charging,
you may press the + button to view the voltage of each
individual cell. You can also view a variety of other information as detailed on
page 13.
Once the battery has reached storage level the screen will read “STORAGE
FINISHED” and the charger will emit a chiming sound. Press the ■ button to
stop charging. You may also press the ■ button at any time during the charging
process to stop charging.
Lithium Discharge Mode:
If you plan to discharge your battery to reach safe storage levels, we strongly
recommend that you use Storage Mode. In very few instances should
discharging become necessary with LiPo batteries. One such instance may
include preparing a battery for disposal, in which case the battery should not be
completely discharged. Be sure to follow the discharging instructions provided
by the battery manufacturer. Over-discharging a battery can severely damage
the battery and may cause a re or explosion.
Lithium Battery Program [LiP0/LiHV/LiFe/Lilon cont.]
DISCHARGING LITHIUM CHEMISTRY BATTERIES CAN CAUSE PERMANENT
DAMAGE TO THE BATTERY AND IT IS NOT RECOMMENDED FOR
ANYTHING OTHER THAN THE DISPOSAL OF THE BATTERY. IF YOU CHOOSE
TO DISCHARGE YOUR LITHIUM BATTERIES, MAKE SURE TO PAY CLOSE
ATTENTION TO THE MINIMUM VOLTAGE SETTING. IF YOU WANT TO STORE
YOUR BATTERY FOR A LONG PERIOD OF TIME YOU SHOULD UTILIZE THE
STORAGE MODE CHARGE PROGRAM AS THIS IS THE SAFEST METHOD OF
STORING YOUR LITHIUM CHEMISTRY BATTERIES.
IN DISCHARGE MODE, LITHIUM BATTERIES CAN BE DISCHARGED
WITH OR WITHOUT THE USE OF A BALANCE ADAPTOR. THE USE OF
A BALANCE ADAPTOR IS RECOMMENDED FOR DISCHARGING ANY
BATTERY THAT HAS A BALANCE LEAD.
See page 12 for the appropriate charging connections setup for this operation.
First, select the correct battery type by following the
instructions above. Once you have set the correct battery
type, press the ► button once to enter the charge mode and battery settings
screen, use the INC. – or DEC + to select “DISCHARGE” mode. Press the ► button
again and the amp rate value will begin ashing. Use the + or ▬ buttons to
adjust the value to the desired rate. Follow the instructions provided with your
battery when setting the charge amperage rate.
Press the ► button again and the voltage value will begin ashing. Use the +
or ▬ buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
You are now ready to begin charging. Press and hold the
ENTER/Start ► button until you see “BATTERY CHECK.”
followed by the “CONFIRM (ENTER) / CANCEL(STOP)“
screen. This screen displays the number of cells you set up
as ”R” and the number of cells detected by the processor as “S”. If both numbers
are identical, you may press and hold the ENTER/Start ► button to conrm and
begin charging. If these numbers do not match, press the BATT/PROG Stop ■
button to return to the previous screen and carefully check the number of cells
of the battery pack before proceeding.
Caution
R:3SE R S:3SER
CANCEL(STOP)
R:3SE R S:3SER
CONFIRM(ENTER)
Warning
LP3s 2.7A 11.88V
STO 005:39 00256
4.07 4.06 4.11V
0.00 0.00 0.00V
Note
LiPo DISCHARGE
2.7A 11.1V (3S)
R:3SE R S:3SER
CANCEL(STOP)
R:3SE R S:3SER
CONFIRM(ENTER)
