User Manual Drives, Cable and Accessories
EM1 Series AC Servo Motors EM1-01-0-EN-2110-MA Page 35 of 72
6.3 Accessories
For the connection arrangement of accessories from 6.3.1 to 6.3.2 please refer to EM1 series
Servo Drive User Manual.
6.3.1 Accessory kit
The accessory kit of EM1 series servo drive is included when the servo drive is shipped out. For
the contents inside the accessory kit, please refer to the table below.
Name HIWIN Part Number Description Qty.
ED1 CK1
accessory kit
(400 W ~ 2 kW Standard)
8-10-1917
CN1: AC main input power terminal, control input power terminal, terminal for
regenerative resistor and terminal for DC reactor (11 pins, TE-2229794-1-PT1)
1
CN2: Motor power connector (3 pins, TE 3-2229794-1) 1
CN4: STO connector (TE 1971153-1) 1
CN6: Control signal connector (50 pins welded type EUMAX XDR-10350AS) 1
Headers and wire housings for CN1 and CN2 connectors (TE1981045-1) 1
ED1 CK2
accessory kit
(400 W ~ 2 kW Fieldbus)
8-10-1918
CN1: AC main input power terminal, control input power terminal, terminal for
regenerative resistor and terminal for DC reactor (11 pins, TE 1-2229794-1-PT1)
1
CN2: Motor power connector (3 pins, TE 3-2229794-1) 1
CN4: STO connector (TE 1971153-1) 1
CN6: Control signal connector (36 pins welded type EUMAX XDR-10336AS) 1
Headers and wire housings for CN1 and CN2 connectors (TE 1981045-1) 1
6.3.2 Power supply filter and accessories
Power supply filter (Optional)
Name HIWIN Part Number Description
Filter
(For single-phase power supply)
8-09-0670
Single-phase filter FN2090-10-06, for
400 W ~ 1 kW models (rated current: 10
A, leakage current: 0,67 mA)
Regenerative resistor (Optional)
Name HIWIN Part Number Description
Regenerative resistor 050100700001 68 /100 W
Regenerative Resistor 050100700004 190 /1.000 W
Note
With heavy load and high acceleration rate, please contact local sales to help for
calculation of regenerative resistor.
