Hiwin EM1 Series User Manual

User Manual Description of the Motors
EM1 Series AC Servo Motors EM1-01-0-EN-2110-MA Page 18 of 72
4.2 Type Code
The model explanation of EM1 series AC servo motor is provided in table below. For further use
with drive, cable and accessory, please refer to chapter 6
.
Number 1 2 3 - 4 - 5 - 6 7 - 8 - 9 - 10 - 11 - 12
Code E M 1 - C - M - 0 5 - 2 - B - E - 0 - A
1, 2, 3 EM1 Mode name
4 C Rated/Max.Speed:
A: 2.000 / 3.000 rpm
C: 3.000 / 6.000 rpm
D: 2.000 / 5.000 rpm
5 M Rotor Inertia:
M: Medium inertia
6, 7 05 Rated output:
05: 50 W
10: 100 W
20: 200 W
40: 400 W
75: 750 W
1K: 1.000 W
1A: 1.200 W
2K: 2.000 W
8 2 Input voltage:
2: 220 VAC
4: 400 VAC
9 B Brake option:
0: Without brake
B: With brake
10 E Encoder option:
E: 23 bit single-turn absolute (battery is not required)
F: 23 bit multi-turn absolute (battery is required)
11 0 Reserved:
0: Standard
1: Customized
12 A Shaft type:
A: Round shaft / without oil seal
B: Round shaft / with oil seal
C: Shaft with key / without oil seal
D: Shaft with key / with oil seal
