HKC HQ-005 Installation, Operation And Maintenance Manual

Installation, Operation and Maintenance Manual
HQ-005 Electric Actuator
Document No. HKQI-611
2 | P a g e
2 PRODUCT IDENTIFICATION
2.1 Product Identification
The actuator name plate is located on the opposite side of the conduit entry. The name plate contains the
following:
2.1.1 Marking
A) General
 HQ logo (trade mark)
 Model
 Torque
 Electrical power supply
 Type
 Rated current
 Operating time (seconds)
 Serial No.
 Option
2.2 Initial Inspection
Upon on the receipt of the actuator, the user should inspect the condition of the product and ensure that
product specification stated in the name plate matches with the order sheet.
 Remove the packing wrap or wooden box carefully. Inspect the product for any physical damage
that may have occurred during shipment.
 Check the product specification with product ordered. If a wrong product has been shipped,
immediately report to our coordinator.
2.3 Storage
Actuators must be stored in a clean, cool and dry area. The unit should be stored with the cover installed and
the conduit openings sealed. Storage must be off the floor, covered with a sealed dust protector. When
actuators are to be stored outdoor, they must be stored off the ground, high enough to prevent from being
immersed in water or buried in snow.
ELECTRIC ACTUATOR
Q U A R T E R T U R N E L E C T R I C A C T U A T O R
MODEL : HQ-005
POWER:AC95-265V,24VAC/DC
OPERATION TIME: SEC.
SERIAL NO:
TORQUE: 5Kgf.m
TYPE: ON-OFF
RATED CURRENT : A
OPTION:

HKC HQ-005 Specifications

General

Brand	HKC
Model	HQ-005
Category	Controller
Language	English
