Installation, Operation and Maintenance Manual
HQ-005 Electric Actuator
Document No. HKQI-611
5 | P a g e
3.2 External Parts for Standard Models
3.3 Internal Parts for Standard Models
External Parts
HQ-005
1
Top Cover
2
Body
3
Star drive (double square 14mm)
4
Mounting base (F03, F04, F05,F07)
5
Manual lever
6
Name Plate
7
Captive cover bolt
8
Beacon Indicator
9
Fully closed LED lamp (red color)
10
Manual hand wheel
11
Fully open LED lamp (green color)
Internal Parts
HQ-005
1
Manual push shaft
2
Indicator
3
PCB
4
Auxiliary Open Switch (White)
5
Closed limit switch (Green)
6
Open limit switch (Red)
7
Auxiliary Closed Switch (Black)
8
Fully closed LED lamp (Red)
9
Fully open LED lamp (Green)
①
②
①
