−32−
４．BasicSettingsGroup
Adjusttheboost'sgainorstabilityforbothAandBModes.
(２)TurnthevolumeknobandsettheOffsetAandBvalue.
Whenthesettingsaredone,pressthevolumeknob.
・Thesettingrangeisbetween1‑199%in1%increments.
・Thedefaultsettingvalueis100%.
・Theboostwillrisewhenthesetvalueisincreased
andviceversa.Thisappliestobothwastegate
typeselections.
(１)PressthevolumeknobintheOffsetASetModeor
OffsetBSetMode.
・Thedigitaldisplay(S)willdisplay[].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willappearinthedisplay.
・TheleftillustrationreferencesOffsetASetMode.
SettheboostvaluetobeaddedtothetargetboostwhentheScramblefunctionistriggered.
(２)Turnthevolumeknobtoselecttheamountofadditional
boostfortheScramblefunction.Aftertheselection,
pressthevolumeknobtoset.
・Thesettingrangeisbetween0‑120kPaor0.0‑17.0PSI
respectivelyfortheunitofmeasureselected.
・Thedefaultsettingis0kPaor0PSI.
(１)PressthevolumeknobwhileintheScrambleBoostSet
Mode.
・DigitalDisplay(S)willilluminate[].
・"ＳＢＣ"willbeilluminatedonthedisplay.
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willbeilluminatedonthedisplay.
４．１．OffsetASetMode/OffsetBSetMode
４．２．ScrambleBoostSetMode
SetthetimedurationoftheaddedScrambleboostforwhentheScrambleistriggered.
(１)PressthevolumeknobwhileintheScrambleTimeSetMode.
・Thedigitaldisplay(S)willilluminate[]
・"ＳＢＣ"willbeilluminatedonthedisplay.
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willbeilluminatedonthedisplay.
４．３．ScrambleTimeSetMode
