−33−
Thewarningfunctionisactivatedwhenthemanifoldpressuregoesexceedstheuserpreset
boostvalue.TheEVCwilldropboosttobaselineboostorbyausersetamountofboost.
(１)WhileintheWarningBoostSetMode,pressthevolume
knob.
・Thedigitaldisplay(S)willilluminated[].
・"ＷＲＮ"willbeilluminatedonthedisplay.
・TheEVCwillbeepandthedigitaldusplay(L)blinks.
・"ＳＥＴ"willbeilluminatedonthedisplay.
(２)Turnthevolumeknobtoselectthewarningboostvalue.
Aftervaluehasbeenselected,pressthevolumeknob.
・Thesettingrangeis0‑250kPaor0.0‑36PSIin
incrementsof1kPaor0.1PSIrespectively.
・Thedefaultsettingvalueis250kPaor36.0PSI.
Note
・Thewarningfunctionisresetwhenthemanifoldpressuredropsbelow5kPa.
Note
・WhilepressingButton①,theScramblefunctionisactivated.However,theScrambletimer
functionwillnotcountdownuntilafterthereleaseofthebutton.WhentheScrambletime
issetto0second,theScramblefunctionisonlyactivewhenthebuttonispressed.
４．４．WarningBoostSetMode
(２)TurnthevolumeknobtoselectthedurationofScramble
Time.Afterselectionisdone,pressthevolumeknob.
・Thesettingrangeisbetween0‑60secondsin1second
increments.
・Thedefaultsettingis0seconds.
Settheamountofboosttodropwhenthewarningfunctionistriggered.
(１)WhileintheDropBoostMode,pressthevolumeknob.
・Thedigitaldisplay(S)willilluminated[].
・"ＷＲＮ"willilluminateonthedisplay
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willilluminateonthedisplay.
４．５．DropBoostSetMode
(２)Turnthevolumeknobtoselectthevalueamountof
boostdrop.Afterselections,pressvolumeknob.
・Thesettingrangeis1‑120kPaor0.1‑17.0PSIin
incrementsof1kPaor0.1PSIrespectively
・Thedefaultsettingis"OFF".(Dropsboosttothe
baselineboostvalue)
