ChangetheRPMaxisgridpoint(divisionpointofthemapbyRPM)forthemap.
(１)PressthevolumeknobwhileintheRPMaxisgridpoint
setmode.
・Thedigitaldisplay(S)willilluminate[].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＬ"willilluminate.
・ThedisplayedRPMvalueis1/100oftheactualRPM.
・Thereare5sequentialgridpoints;"1"isthelowest
and"5"isthehighest.
５．３．RPMAxisGridPointSetMode
(２)Turnthevolumeknobtoselectthegridpointtochange.
PressButton①tochangetheRPM.
・Whenthegridpointischanged,theRPMsetting
displayisalsochanged.
・PressingButton①advancestostep(３)."ＳＥＬ"will
disappearas"ＳＥＴ"willappear.Thedigitaldisplay
(L)stopsblinking&theRPMsettingdisplaywillblink.
(３)TurnthevolumeknobandchangetheRPMcorresponding
tothegridpoint.Whenthesettingisdone,pressthe
volumeknobagain.
・TochangetheotherRPMsettings,pressButton①and
gobacktostep(２)andrepeatprocedure.
Note
・Thedefaultgridpointsettingsareasfollows:1:2000rpm,2:3000rpm,3:4000rpm,4:5000rpm,
5:6000rpm.
・TheRPMsettingrangeisbetween0‑12000rpm.Eachgridpointsettingvalueshouldbe
+100rpmofthepreviousgridpointand‑100rpmofthenextpoint.
Note
・Thedefaultgridpointsettingsareasfollows:1:0km/h,2:50km/h,3:100km/h,
4:150km/hand5:200km/h.
・Thevaluesettingrangeisbetween0‑500km/h.Eachgridpointsettingvalueshouldbe
+10km/hofthepreviousgridpointand‑10km/hofthenextpoint.
(１)PressthevolumeknobwhileintheRPMaxisgridpoint
setmode.
・Thedigitaldisplay(S)willilluminate[].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＬ"willilluminate.
・Thereare5sequentialgridpoints;"1"isthelowest
and"5"isthehighest.
Changethethrottleaxisgridpoint(divisionpointofthemapbythrottleopening%)for
themap.
５．４．ThrottleAxisGridPointSetMode
