HKS EVC - Page 42

(１)Pressthevolumeknobwhileinthecylinder#setmode.
・Thedigitaldisplay(S)willilluminate[ ].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＬ"willilluminateonthedisplay.
Settheamountforthenumberofcylindersofengine.(ForusefortheRPMsignalinput)
７．１．Cylinder#SetMode
CAUTION
●
SettingsmustbedonewiththeengineOFF.
−41−
７．VehicleSettingGroup
ForoptimumperformanceoftheEVC,selecttheappropriateselectsfortheapplication.
(２)Turnthevolumeknobtoselectthenumberofcylinders.
Pressthevolumeknobaftertheselection.
・Selectfrom:１・２・３・４・６・８ofcylinders.
・Thedefaultsettingis"４"for4cylinders.
Setthespeedpulseforthespeedsignalinput.
７．２．SpeedPulseSetMode
(１)Pressthevolumeknobwhileinthespeedpulseset
Mode.
・Thedigitaldisplau(S)willilluminate[ ].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＬ"willilluminateonthedisplay.
(２)Turnthevolumeknobtoselectthespeedpulse
setting.Pressthevolumeknobaftertheselection.
・Selectfrom:２・４・８・１６pulses.
・Thedefaultsettingis"４"pulses.
Note
・Forrotaryengines,select"４"for２rotorenginesand"６"for３rotorengines.
Note
・ForNissanY32Gloria/Cedricusesetting16,forY32Cimausesetting8andfor
allotherNissanvehiclesusesetting2.ForotherJDMvehiclesusesetting4.
