TousethethrottlesignalinputoftheEVC,youmustsettheThrottle‑Offvoltagevalue.
７．３．Throttle‑OffVoltageSetMode
(１)PressthevolumeknobwhileintheThrottle‑Offset
mode.
・Thedigitaldisplay(S)willilluminate[ ].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willilluminateonthedisplay.
(２)Thecurrentthrottlevoltageisdisplayed.Whenthe
iconisilluminated,thevoltagewillbeautomatically
determined.Toensurethatthethrottleiscompletely
closed,stepontheacceleratorpedalandthenrelease.
Afterconfirmingthatitisclosed,pressthevolume
knobtosetthevalue.
・TheEVCwillbeepandthevoltagevalueisnowset.
−42−
Note
・Thedefaultvalueis０．５０Ｖ.
TousethethrottlesignalinputoftheEVC,youmustsettheFullThrottlevoltagevalue
７．４．FullThrottleVoltageSetMode
(１)PressthevolumeknobwhileintheFullThrottleset
mode.
・Thedigitaldisplay(S)willilluminate[ ].
・TheEVCwillbeepandthedigitaldisplay(L)blinks.
・"ＳＥＴ"willilluminateonthedisplay.
(３)Thethrottle‑offvoltagevaluecanalsobemanually
inputted.PressButton①andtheiconwillnow
illuminate,indicatingyouareinmanualmode.Turn
thevolumeknobtoselecttheclosedvoltageandpress
thevolumeknobtoset.
・TheEVCwillbeepandthevoltagevalueisnowset.
(２)Thecurrentthrottlevoltageisdisplayed.Whenthe
iconisilluminated,thevoltagewillbeautomatically
determined.WiththeengineOFF,firmlysteponthe
acceleratorpedaluntilitreachesthestopper.After
confirmingthatitisfullyopen,pressthevolume
knobtosetthevalue.
・TheEVCwillbeepandthevoltagevalueisnowset.
