Verify Operation 85 (124)
Status Symbols
Symbol Description
Internal error has occurred and operation cannot be guaranteed.
Out of Specification.
Check Function:
• Initial state where non network components are started and configured.
• Network startup in progress.
• Invalid configuration detected.
Normal operation.
