3 Preparation
3.1 Cabling
Have the following cables available:
• Ethernet cable for configuration
• Ethernet cable for connecting to the high level network
• Power cable
3.2 System Requirements
3.2.1 Supported Operating Systems
Operating System Description
Windows 7 SP1, 32-bit Windows 7 32-bit with Service Pack 1
Windows 7 SP1, 64-bit Windows 7 64-bit with Service Pack 1
Windows 10 64-bit Windows 10 64-bit
3.2.2 Supported Web Browsers
The Communicator built-in web interface can be accessed from the following standard web
browsers.
• Google Chrome
• Microsoft Edge
• Mozilla Firefox
3.3 Tools
Have the following tools available:
• Flat-head screwdriver, size 5.5 mm
Needed when removing the Communicator from DIN-rail.
• Flat-head screwdriver, size 3 mm
Needed when connecting the cables to the 7-pin connector.
3.4 Support and Resources
For additional documentation and software downloads, FAQs, troubleshooting guides and
technical support, please visit www.anybus.com/support.
Have the product article number available, to search for the product specific support web page. You find
the product article number on the product cover.
