Hobart GPU-600 - Page 69

NOMENCLATURE UNITS
FIGURE HOBART EFF PER
ITEM NO. PART NO. 1234567 ASSY
1- S-6883-1 GPU-600, 60-Hz, 208/230/460 VAC A 1
S-6883-2 GPU-600, 50-HZ, 220/380 VAC B 1
S-6883A-1 GPU-600, 60-Hz, 208/230/460 VAC C 1
S-6883A-2 GPU-600, 50-HZ, 220/380 VAC D 1
S-6883A-3 GPU-600, 60-Hz, 230/460/575 VAC E 1
1 12CW-2170 . GROMMET, TOP
2 489584 . PANEL, TOP 1
3 489591 . YOKE, LIFTING ASSY,
(For Details See Fig. 2) AC 1
180364 . YOKE, LIFTING ASSY,
(For Details See Fig. 2) BDE 1
4 489586 . PANEL, SIDE, RIGHT 1
5 489603 . PANEL, REAR 1
6 201016 . SHROUD, FAN 1
7 406991 . BLADE, FAN, V35197, NO. 603S72 1
8 406992-1 . MOTOR, FAN, V62119, NO. CAZJ192 1
9 201015 . BRACKET, MOTOR 2
10 489573 . BASE, MTG., ASSY. 1
11 489590 . PANEL, SIDE, LEFT 1
12 487813 . DOOR, ACCESS ASSY. 2
13 489561 . TRANSFORMER, POWER A-D 1
181565 . TRANSFORMER, POWER E 1
13A 367229-3 . BOARD, VOLTAGE CHANGEOVER, ASSY 1
14 180065 . SHUNT, 2000A 1
15 489608 . BARRIER, TERMINAL OUTPUT 1
16 180480 . CHOKE, ASSY. A-D 1
487952 . CHOKE, ASSEMBLY E 1
17 405278-7 . CAPACITORS, V56289, NO. 36DX772F200DF2A A-D 3
405278-7 . CAPACITORS E 3
18 489655 . DOOR, ACCESS, ASSY. 1
19 (Deleted)
20 489610 . BRACKET, OUTPUT CABLE 1
21 489971 . SPACER, OUTPUT CABLE 2
22 489700 . RECTIFIER, OUTPUT
(For Details See Fig. 3) 1
487050-2 . RESISTOR AY 1
23 AAW-1199 . BRACKET, MTG, RESISTOR 2
24 16DA-3493 . WASHER INSULATING 6
25 403765-2 . RESISTOR, FIXED, V44655, NO. 0600B 3
26 397752-1 . BRACKET, CABLE HANGER 4
27 486143-2 . SPACER, WHEEL 2
28 83B-1101 . WHEEL 10", MATERIAL HANDLING ASSOC,
NO. 3875-10 2
March 17/93 Revised 4-3
