NOMENCLATURE UNITS
FIGURE HOBART EFF PER
ITEM NO. PART NO. 1234567 ASSY
1- (Continued)
29 W-11242-14 . WASHER, FLAT 4
30 W-11338-3 . COTTER PIN 2
31 83B-1100-1 . CASTER MATERIAL HANDLING ASSOC,
NO. 6-43-126-7 1
32 83B-1100-2 . CASTOR WITH BRAKE, NO. 6-43-126-7
MATERIAL HANDLING ASSOC. 1
33 910225-1 . HANDLE ASSY. 1
34 350488-94 . . INSULATION, CAPACITOR 3
35 361052-9 . . CLAMP, CAPACITOR, V90201, NO. VR12 3
36 351541 . LABEL, CAUTION FAN 1
37 81B-1061 . LABEL, RECTIFIER SHOCK 1
38 83B-1079 . LABEL, ELECTRIC SHOCK 2
39 83A-1105 . LABEL, FUSES 1
40 489588- . PANEL, FRONT ASSY.
(For Details See Fig. 4)
1
489588-2 . PANEL, FRONT ASSY.
(For Details See Fig. 4)
1
41 487979 . SPACER, PC PANEL A-D 1
487979 . SPACER, PC PANEL E 2
42 487964 . CABLE HANGER 4
489974 . TERMINAL, OUTPUT, ASSY. 2
44 No Number . . SCREW - 3/8-16 X 2-1/2 HHC ST.
(STD)
2
46 489973 . . BOARD, MTG. TERMINAL OUTPUT 1
45 489972 . . SUPPORT, TERMINAL OUTPUT 1
47 No Number . . SCREW 1/4 X 1-1/4 HHC
(STD)
2
48 No Number . . WASHER FL. ST 1/4 4
49 No Number . . WASHER LK. ST 1/4 2
50 No Number . . NUT, 1/4-20 HEX FULL ST. 2
51 No Number . . WASHER FL. ST. 3/8 6
52 No Number . . WASHER LK. ST. 3/8 4
53 No Number . . NUT 3/8-16 HEX FULL ST. 4
* 54 402674-2 . . LABEL POSITIVE 1
* 55 402674-1 . . LABEL NEGATIVE 1
* 56 84A-1054 . REFLECTOR 4
* 57 80A-1133 . CABLE, STRAIN RELIEF 1
* 58 367579 . INSULATOR, FUSE BLOCK 1
*59 W-11166-9 . FUSE, FAST BLOW, AGC, 1 AMP 6
* NOT ILLUSTRATED
March 17/93 Revised 4-3
Page 5
OM-2010
