NOMENCLATURE UNITS
FIGURE HOBART EFF PER
ITEM NO. PART NO. 1234567 ASSY
4- 489588-1 PANEL, FRONT ASSY (For NHA See Fig. 1) ACE REF
489588-2 PANEL, FRONT ASSY (For NHA See Fig. 1) BD REF
1 489587 . . PANEL, FRONT AC 1
180373 . . PANEL, FRONT BD 1
2 408446 . . LABEL 1
3 404277 . . COVER, RECEPTACLE, DUPLEX, V81703,
NO. WPDC ACE 1
404355 . . COVER, RECEPTACLE, DUPLEX, V91929, NO.
W-948A 1001 BD 1
4 405072-2 . . DIODE, LIGHT-EMITTING, V71744, NO.
TYPE 6080-002-304 1
5 402670 . . RECEPTACLE, 3-WIRE, 15A, 115V V74545,
NO. 5000-M9 ACE 1
404336 . . RECEPTACLE, 3-WIRE, 15-A, 277-V,
TWIST-LOCK, V77166 BD 1
366826- . . SUPPRESSOR, ASSY. 1
6 401532-2 . . . SUPPRESSOR, THYRECTOR, DIODE,
V81483, NO. KZ4DTM ACE 1
403955-3 . . . SUPPRESSOR, THYRECTOR, DIODE, BD 1
7 402197-1 . . . TERMINAL, RECEPTACLE, F-CRIMP,
18-14, V00779, NO. 61944-2 ACE 2
8 401428-1 . . POTENTIOMETER, 10K OHM, 2W, V01121,
NO. JAIN056S103UA 1
9 405734 . . CLIP RETAINER, LED V71744, NO. 217-907-19 1
10 403189 . . SWITCH, TOGGLE, 3 POSITION, V91929, NO. 312TS 1
11 400400 . . SWITCH, TOGGLE, V74559, NO. 2GL61TAB 1
12 404173 . . BASE, LIGHT PILOT, V72619, NO. 26-1310-11-301 2
13 404172-2 . . LENS, LIGHT PILOT, AMBER, V72619,
NO. 26-1193-300 1
14 400613-6 . . LAMP, 120V, V71774, NO. 120MB 1
* 15 403247 . . LABEL, ELECTRIC SHOCK
(on rear of panel)
1
16 400642-3 . . VOLTMETER, DC, 0-50V, V60741, NO. PER
HB DRAWING 1
17 16DA-2162 . . KNOB, RHEOSTAT, V44655, NO. 5150 1
18 402658 . . HOLDER, FUSE, V71400, NO. HKP-HH ACE 1
402658 . . HOLDER, FUSE, V71400, NO. HKP-HH BD 2
19 W-11166-4 . . FUSE, FAST BLOW, V71400, NO. AGC-15 1
20 400641-12 . . AMMETER, DC, 5O mV, V60741, NO. PER
HB DRAWING 1
21 404172-3 . . LENS, LIGHT, PILOT, GREEN, V72619,
NO. 26-1192-300 1
22 400613-6 LAMP, 28V, V71744, TYPE 757, STYLE T-3-1/4 1
23 489581 . . NAMEPLATE, IDENTIFICATION 1
24 400647-8 . . FUSE, FASTBLOW V71400 BD 1
* NOT ILLUSTARTED
OM-2010
December 16/91 Revised 4-3
Page 11
