Hobart Handler 210 User Manual

OM-227 978 Page 41
Problem RemedyProbable Cause
Welding arc not stable.
Wire slipping in drive rolls. Adjust pressure setting on wire feed rolls. Replace worn
drive rolls if necessary.
Wrong size gun liner or contact tip. Match liner and contact tip to wire size and type.
Incorrect voltage setting for selected wire feed speed on
welding power source.
Readjust welding parameters.
Loose connections at the gun weld cable or work cable. Check and tighten all connections.
Gun in poor shape or loose connection inside gun. Repair or replace gun as necessary.

Hobart Handler 210 Specifications

General

Input Voltage	230 V
Amperage Output	25 - 210 A
Weldable Materials	Steel, Stainless Steel, Aluminum
Welding Processes	MIG (GMAW), Flux-Cored (FCAW)
Input Frequency	60 Hz
Output Current Range	25 - 210 A
Wire Feed Speed Range	50-700 IPM
Weight	79 lb
Spool Size Capacity	4 or 8 in.
Input Phase	1-Phase
Duty Cycle	20% @ 90A
