Hobbico Spectrum - Know Your Models Parts

2
Take a moment now to
match the box contents
with the items listed
below. Following the
Spectrum assembly
instructions will be
quite
easy if you
identify and
organize the parts
before you begin.
Replacement Parts Available
HCAA3710...Wing Kit HCAA3714....Canopy
HCAA3711 ...Fuselage Kit HCAA3715....Landing Gear Set
HCAA3712...Fin Set HCAA3716....Spinner
HCAA3713...Cowl
Landing Gear
Part # Quantity
5 Landing Gear Blocks.................2
6 Landing Gear Struts (L&R) .......2
7 Wheels ......................................2
8 Tail Wheel..................................1
9 Landing Gear Cover Plates.......2
10 Plastic Gear Cover....................2
Wing Assembly
Part # Quantity
11 Wing Joiner..............................................1
12 Right Wing Panel .....................................1
13 Left Wing Panel .......................................1
14 Wing Bolt Plate ........................................1
15 Aileron Servo Covers...............................2
16 Retract Wheel Wells ................................2
17 Wing Mounting Plate................................1
18 Aileron Servo Tray ...................................2
19 Front Root Ribs........................................2
20 Rear Root Ribs ........................................2
* Clevises ...................................................2
* 4 x 35mm Bolt..........................................2
* 4mm Washer............................................2
18
14
Clevis
4mm
Washer
You’re about to build in just hours what took aviation
pioneers years—a powered machine that flies. Specially
created for you and other experienced radio control
modelers, Hobbico’s Spectrum offers nearly all the
excitement of piloting a real airplane...and develops skills
that will take you anywhere you want in your hobby.
*Parts marked with an asterisk are found on the plastic parts tree.
Know Your Model’s Parts
Engine Mounting Parts
Part # Quantity
1 Engine Mount ....................................1
2 Pushrod Tubes ..................................2
3 Pushrod Wire.....................................2
4 Pushrod Tubes ..................................2
4 x 35mm
Bolt
