7. Electrical Installations
127
TV unit
Theinstallationareafortheat-screenTVdiersfrommodel
to model.
Therequiredconnectionscanbefoundrightnexttothis
space,possiblyinacupboard.
TV connections
ThecorrespondingconnectionfortheSATantenna(E3)isfed
outopenlyinthepositionappropriateforthemodelinquestion.
Thepowercable(E3)hasalreadybeenconnectedbythema-
nufacturertothecontrolpanel.
Cable colours:
white = mass
black= steadyplusforancillarybattery
brown= D+signal
Antenna and digital SAT cable
