7. Electrical Installations126
Fiat interface module
The interface moduleprotects the superstructure's outside
lights:therightandleftsidemarkerlightsaswellasthefront
positionlights(
j
5Ampfuse).
Position of the interface module
B-pillaronthepassengerside(right-handsideinthedirection
oftrac)behindtheplasticcasinginthelowersection.
1
Interface module
Light Control System
Theoutputsare protectedby internal circuitbreakers (poly-
switchfuses).Thesefusesareself-resettingandcanbereused.
Itisnotpossibletoexchangethem,becausetheydonotrequire
maintenance.
Contact plan for the light control system
