7. Electrical Installations124
j
Socket;themiddlepinisthesensor.
k
PCBswitches.Theswitchesmustallbeinthetopposi-
 tion,i.e.allsetto“o”.
l
Changeovercontact,forfreedisposal.
m
Contactbridge,fanon/o.
n
LEDblinkstoshowcurrentchargingmode.
1 2
3
4
5
Charger connections
All12Velectricaldevicesaresupplieddirectlybytheancillary
battery.In230Vmainsoperation,theyarechargedautomatically
by the battery charger.
Allofthelampsinthemotorhomeuse12VLEDlights.
Only large electrical devices such as the Combi E heating*,
air-conditioningsystem,etc.,use230V.
7.4 Electrical system
Assignment of fuses
Assignment of fuses
The fuses for the individual internal electric circuits are loca-
tedintheinputmodule.
Insomemodels,theremaybeslightdeviationsinthis
assignment.
Onlyreplacedefectfusesifyouknowwhatcausedthe
fusetoblowandhavexedthis.
