HOBIE 15 CLUB
TABLE OF CONTENT
List of the parts.......................... 3
Hull assembly............................ 4
Trampoline .............................5-6
Rudder assembly ...................... 7
Tiller crossbar and extension .... 8
Mast set-up...........................9-10
TOOLS NECESSARY
1 x #14 wrench
1 x # 10 wrench
1 x pair pliers
LIST OF THE PARTS
1 Hulls (2)
2 Front Crossbar
3 Rear Crossbar
4 Sidebars (2)
5 Mast
6 Trampoline (3 pieces)
1
1
2
3
4
4
5
6
7
8
9
10
10
11
12
13
14
Raising the mast ................ 11-12
Mainsail....................................13
Main traveller ...........................14
Mainsheet system....................15
Preparation for sailing..............16
Safety advice ...........................17
7 Rigging Bag
8 Wire Bag
9 Rope Bag
10 Rudder assemblies (2)
11 Tiller Crossbar
12 Tiller extension
