05
2.Mounting the Quick Release Plate
a. Mount the camera onto the camera quick release plate, and tighten the screw.
It is required to tighten the screw in case of gimbal shaking when
the gimbal is powered on.
b. Loosen the L-Bracket with the
thumb screw wrench (magnetically
attached to the L-Bracket.) Adjust
the L-Bracket according to the width
of the action camera and tighten
the screw after tting properly.
c. Attach the camera with the quick release plate onto the L-Bracket.
To Next Page
