15 Buscongurationmenu
Thismenuisofinteresttoyou,ifyouhaveadatacollector(DEL-
TAXLorHELIOTEX).Ifyouwanttomakeanetwork,pleaseread
thoroughlytheinstructionsthatcomewiththesoftwareatrst.In
thismenu,youcanmakesettingsfornetworkingtooperatethe
data collector.
Thiswilltakeyoutothebuscongurationmenu:
NEXT
PROG
NEXT
+
Following menu options are successively programmable:
insertmastercard
hold
press 1x
unhold
YoucanchangethevaluesafteryourdesirewithhelpofPLUS
andMINUSbutton.WithNEXTbuttonyoucallupthenextpo-
sition.
Display shows Factory setting Description
Device address 1 BeiderGeräteadressehabenSiedieMöglichkeit,demUNOimBus-System
eineAdressezwischen 1-36 zuzuordnen.Dabeiist daraufzu achten, dass
zweiGerätenichtdieselbeAdressebekommen.
JedesXL-GerätmusseineandereGerätenummerbekommen!Esdürfenkei-
neNummerndoppeltvergebenwerden,sonstistdasBus-Systemnichtinder
Lage die jeweilige Adresse auszulesen.Außerdem müssen die Gerätenum-
mern mit den im SkinControl® eingestellten Nummern und der zugehörigen
Kabine(demjeweiligenSolarium)übereinstimmen.
Card verify no Thissettingmustbesetgenerallyto"no".If"yes"isset="no contact to the
control panel"
Testing no Withsettingtestingyouhavethepossibility,toblocktheerrormessagesout
withsetting"no".Thestandardsettingis"no".
Baudrate 9600 Withthesettingbaudrate, you havethepossibility to setvariousdata trans-
ferspeed.Thesmallerthenumbertheslowerthedatatransfer.Youhavethe
possibilitytochoosebetween1200,2400,4800,9600,19200,and38400.The
standard setting is 9600 baud.
Parität even Withthesettingparity,youhavethepossibility,tocheckthesentdataformis-
takes.By the setting “even”,the even number bitswillbe checked, withthe
setting“uneven”,the“uneven”numbers.Nocheckingwillbecarriedout,with
thesetting"none".Thestandardsettingis"even".
