5 Devicespecicdata
After switching on the electricity on the display appears for
approx.2seconds:HoltkampXLX.x,belowinthesecondrow:
T-Timer. This is information about the used software version
(X.x)aswellastheoperatingtypeoftheUNO(T-Timer).These
detailsaresubjectoftheadvanceddevelopmentoftheUNOand
your order.
Lockingno.(embossedonthekey)
Operating type and software version (the display appears it as
number,2secondsafteractivate)
Serial-Number (written on the type plate)
Commission
Trader
Forfurtherquestionsandordersthesedetailswillconstitutean
advantage. Please note all the abbreviations appearing on the
display,denitely, foranyother technicalrequests, inthe follo-
wing list.
6 General details
Casingmaterial Stahlblechverzinkt2mm
Casing colour pulverbeschichtet weiß RAL 9016 *
Dimensions H300mmxB218mmxT141mm
Power supply 230Voder24V,50/60Hz
Switchedpower 6,3Abeicosphi=1
Power absorption 10 VA
Cable entrance vonhinten(3Bohrungen)
Temperaturerange 0°C - 50°C
Protection class Ibei230V~bzw.IIIbei24V~
Protection type IP 20
Weight(withemptycoin-bag) ca.7,5kg
Gewicht(mitvollemMünzsack) ca.15kg
Weight (with full coin-bag) 100mAT
FusecircuitboardSI2 6,3AMT
FusemainrelaySI3 6,3AMT
Attention: Fuses may only be replaced with the same value!
