Drechselbank / wood turning lathe D 460FXL
11 TECHNIC
11.1 Components of the machine
1 cover drive belt 6 small tool rest
2 face plate 7 4-side grab chuck
3 large tool rest 8 motor
4 tailstock 9 potentiometer
5 ON/OFF switch D460 10 toolrest with eccentric clamp
5a ON/OFF switch D 460FXL 11 machine bed
5
2 1
8
7
6
