ERSATZTEILE / SPARE PARTS
HOLZMANN Maschinen GmbH www.holzmann-maschinen.at Seite 29
Drechselbank / wood turning lathe D 460FXL
18.1.2 Stückliste / spare part list
Nr. BESCHREIBUNG / DESCRIPTION Stk
1 Hand Wheel 1 42 Nut M10 2
2 Hex Socket Screw M6×12 4 43 Flat Head Screw 1
3 Collar Spindle 1 44 Spring Washer 1
4 Ball Bearing 80105 2 45 Handle 1
5 Hex SocketT Screw M8×25 4 46 Lock Screw 1
6 Washer 6 47 Hex Socket Screw M8×12 1
7 Rear Belt Door 1 48 Motor Plate 1
8 Moving Knob 1 49 Big Washer 3
9 Stationary Knob 1 50 Washer 6 3
10 Bolt 1 51 Motor Pulley 1
11 Semi-circle Head Screw 1 52 Drive Pulley 1
12 Headstock 1 53 Drive Belt 1
13 Retaining Ring 2 54 Bolt 1
14 Headstock Spindle 1 55 Washer 1
15 Face Plate 1 56 Door Latch 1
16 Headstock Spur Center 1 57 Washer 4 1
17 Lock Handle For Tool Rest Base 1 58 Hinge 2
18 Retaining Ring 10 3 59 Semi-circle Head Screw M4×8 2
19 Tool Rest Bushing 1 60 Switch-box Plate 2
20 Tool Rest (150mm ,300mm) 1 61 Pin Hinge 1
21 Tool Rest Base 1 62 Power Cord 1
22 Tool Rest Cam Follower 1 63 Overload Protector 1
23 Flat Head Screw 2 64 Line Board 1
24 Spring 2 65 Semi-circle Head Screw M4×6 4
25 Handle 2 66 Switch-box 1
26 Lock Bolt 2 67 Knob 1
27 Cup Center 1 68 Switch 1
28 Ball Bearing 80102 1 69 Hex Socket Taper Screw M6×12 4
29 Taper Rod 1 70 Motor 1
30 Tailstock Quill 1 71 Rubber Washer 4
31 Tail Axis 1 72 Nut M10 4
