ERSATZTEILE / SPARE PARTS
HOLZMANN Maschinen GmbH www.holzmann-maschinen.at Seite 30
Drechselbank / wood turning lathe D 460FXL
32 Tailstock 1 73 Retaining Ring 1
33 Eccentric Axis 1 74 Washer 4
34 Quill Adjusting Wheel 1 76 Flat Head Screw 3
35 Quill Crank Handle 1 77 Extension Bed 2
36 Bolt 1 78 Plate 2
37 Cam Follower Tailstock 1 79 Screw 1
38 Bed 1 80 Cover 1
39 Retaining Plate 1 81 Variable Plate 1
40 Hex Socket Screw M10×12 2 82 Screw 2
41 Lock Plate 2 83 Transformer 1
