ERSATZTEILE / SPARE PARTS
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 34
TK 255
No.
Name
Qty.
1
ST3.5X16 cross recessed pan headtapping screw
4
2
overload switch
1
3
ST3.9x10 cross recessed pan headtapping screw
5
4
inductance
1
5
capacitance
1
6
switch box
1
7
switch（KJD12）
1
8
ST3.9X14 cross recessed pan head tapping screw
2
9
label for body
1
10
M6 locking nut
2
11
big hand wheel
1
12
ø6 big flat washer
18
13
small handle
1
14
ø 8 flat washer
4
15
M6 stepped screw
1
16
angle location
2
17
M5x14 cross recessed big pan head screw
2
18
gear rack
1
19
M4x12 cross recessed pan head screw
3
20
M4x8cross recessed pan head screw
18
21
pointer of body
1
22
ø4spring
5
23
M4 hex nut
2
24
M4X8 cross recessed countersuck screw
5
25
rubber foot
4
26
machine body
1
27
ST3.5X 10 cross recessed pan head tapping screw
4
28
coiling hook (left)
1
29
tooling box
1
30
sleeve
1
31
knob for tooling box
1
32
φ30X8X3 flat washer
1
33
coiling hook(right)
1
34
M5 locking screw
1
35
M6x30 cross recessed pan head screw
4
36
M6x22 cross recessed pan head screw
1
37
saw blade location block
1
38
washer for blade guard
2
39
M6 star nut
1
40
big torision
1
41
ø3x25pin
1
42
rotate axis
1
43
M4 stepping screw
1
44
pressure handle
1
45
location ring
1
46
ø10xø26x1.5plastic washer
1
47
M6x40 cross recessed counter suck screw
1
48
axle sleeve（1）
1
49
location block
1
50
axle sleeve（2）
1
51
fasten bar
1
52
M5x10 cross recessed pan head screw
10
53
gear
2
54
M4x20 cross recessed counter suck screw
2
