ERSATZTEILE / SPARE PARTS
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 35
TK 255
55
pointer seat
1
56
M4x6 cross recessed pan head screw
3
57
rotate support(1)
1
58
M5x10 cross recessed counter suck screw
4
59
rotate bar(1)
1
60
rotate location block
2
61
ø5 big flat screw
18
62
M6x16 inner hex screw
6
63
ø6spring
8
64
5x12cross recessed pan head screw
2
65
motor support board
1
66
output guard
1
67
M5x6 cross recessed pan head screw
8
68
saw blade guard1
1
69
M6x20 hex screw
6
70
pressure block
2
71
washer
2
72
rotate support（2）
1
73
rotate bar(2)
1
74
rotate location board
1
75
M6x12 hex screw
4
76
M10 locking nut
2
77
ø10 flat washer
3
78
fasten location block
1
79
saw blade guard2
1
80
ST3.9x12 cross recessed pan head tapping screw
5
81
cover block
1
82
M14 hex nut
1
83
outer pressure board
1
84
saw blade
1
86
push sticker
1
87
saw balde location ring
1
88
inner pressure board
1
89
M5x12 cross recessed counter suck screw
3
90
bearing housing
1
91
6003 bearing
1
94
ø35 snap spring
1
95
output axis
1
96
flat key5x5x12
1
97
big gear wheel
1
98
ø16 shaft circlip
1
99
HK1210neddle baring
1
100
Middle cover
1
101
M8 lock nut
1
102
ø4 teech washer
3
103
6202 bearing
1
104
screw bar
1
105
rotor
1
106
629bearing
1
107
ST4.8x60cross recessed pan head screw
2
108
stator
1
109
fan shroud
1
110
motor housing
1
111
brush holder
2
112
carbon brush
2
