Treadmill A90-248 ~ 3 ~
3 ASSEMBLY SPECIFICATIONS
Step 1: Connect part F #M8*45 screws on the screen with part G#M8 nut, then connect signal wires together.
Pull up the electronic watch in the direction of the arrow and fix it on the column with part E #M8*15 screws
and part D #M8 flat pads.
Step 2: Pull up the column and fix it on the frame with part E (# M8*15) screws and part D (#M8) flat pad.
If the treadmill you purchased is a multi-functional treadmill, please continue the installation in the following steps:
Number Parts Description
4 Message Helmet
5 Screw
6 Gasket
