Function and device overview
3 Function and device overview
The Homematic IP Shutter Actuator is suitable for instal-
lation with a flush-mounting or surface-mounting box
and oers individual control of connected AC motors
used with shutters and awnings.
Thus, electrically operated window coverings are moved
up and down automatically.
Shutters and awnings are operated easily via an external
push-button, via remote control or the Homematic IP
app.
Device overview (see fig. 1):
(A) System button (reset button und LED)
(B) Fixing lug
(C) Connecting terminal 2 (motor „up“)
(D) Connecting terminal 1 (motor “down”)
(E) Connecting terminal for L (phase conductor)
(F) Connecting terminal for N (neutral conductor)
(G) Connecting terminal for S1 (push-button input
“down”)
(H) Connecting terminal for S2 (push-button input
“up”)

Homematic IP HmIP-FROLL Specifications

General

Operating temperature (T-T)	-10 - 55 °C
Frequency	868.6 MHz
Product type	Transmitter
Certification	CE
Product color	White
Maximum outdoor range	180 m
International Protection (IP) code	IP20
Current	2.2 A
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	41 mm
Width	54 mm
Height	33 mm
Weight	40 g
Package depth	112 mm
Package width	122 mm
Package height	48 mm
Package weight	121.2 g
