Homematic IP HmIP-FROLL User Manual

34
Start-up
5.3 Teaching-in
Please read this entire section before starting
the teach-in procedure.
First set up your Homematic IP Access Point via
the Homematic IP app to enable operation of
other Homematic IP devices within your system.
For further information, please refer to the oper-
ating manual of the Access Point.
You can connect the device either to the Access
Point or to the Homematic Central Control Unit
CCU2. For detailed information, please refer to
the Homematic IP User Guide, available for down-
load in the download area of www.eQ-3.de.
To integrate the shutter actuator into your system and
enable it to communicate with other Homematic IP
devices, you must teach-in the device to your
HomematicIP Access Point first.
To teach-in the shutter actuator, please proceed as
follows:
• Open the Homematic IP app on your smart-
phone.
• Select the menu item “Teach-in device”.
• After installation, the teach-in mode remains ac-
tivated for 3 minutes.

Homematic IP HmIP-FROLL Specifications

General

Operating temperature (T-T)	-10 - 55 °C
Frequency	868.6 MHz
Product type	Transmitter
Certification	CE
Product color	White
Maximum outdoor range	180 m
International Protection (IP) code	IP20
Current	2.2 A
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	41 mm
Width	54 mm
Height	33 mm
Weight	40 g
Package depth	112 mm
Package width	122 mm
Package height	48 mm
Package weight	121.2 g
