Homematic IP HmIP-FROLL User Manual

31
Start-up
Installation may only take place in normal com-
mercial switch boxes (device boxes) in accord-
ance with DIN 49073-1 or surface-mounting
boxes in accordance with DIN 60670-1 (e.g. Abox
025 or Abox 040).
Please observe the hazard information in section
„2 Hazard information“ on page 24 during in-
stallation .
Permitted cable cross sections for connecting to the
shutter actuator are:
rigid cable [mm
2
] flexible cable with/without ferrule
[mm
2
]
0.75 - 1.50 0,75 - 1,50
5.2 Installation
You can install the shutter actuator
• in a flush-mounting box or
• in a surface-mounting box.
5.2.1 Flush-mounting box installation
To install the shutter actuator in a flush-mounting box,
please proceed as follows:
• Switch o the fuse of the power circuit.
• Connect the switched phase conductors for con-

Homematic IP HmIP-FROLL Specifications

General

Operating temperature (T-T)	-10 - 55 °C
Frequency	868.6 MHz
Product type	Transmitter
Certification	CE
Product color	White
Maximum outdoor range	180 m
International Protection (IP) code	IP20
Current	2.2 A
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	41 mm
Width	54 mm
Height	33 mm
Weight	40 g
Package depth	112 mm
Package width	122 mm
Package height	48 mm
Package weight	121.2 g
