18
Hazard information
disconnect the mains voltage (trip
the miniature circuit-breaker).
Non-compliance with the installa-
tion instructions can cause fire or
introduce other hazards.
Mains supply and SELV/PELV pow-
er circuits may not be connected
together (in combination) to the
dierent switching outputs.
For secure operation, the device
has to be installed in a power distri-
bution panel according to VDE
0603
, DIN 43871 (low-voltage
sub-distribution board), DIN 18015-
x. The installation must be carried
out on a mounting rail (DIN rail)
according to EN 60715. Installation
and wiring have to be performed
according to VDE 0100 (VDE 0100-
410, VDE 0100-510 etc.). Please
consider the technical connection
requirements (TAB) of your energy
supplier.
When connecting to the device
terminals, take the permissible
cables and cable cross sections
into account.
Connected loads require sucient
insulation.
Exceeding this capacity could lead
to the destruction of the device,
fires or electric shocks.
Before installation and connection
of the device, mains voltage must
be disconnected and live parts in
the surrounding must be covered.
The load current circuits have to
be secured by a cable protection
switch in accordance with
EN60898-1 (tripping characteris-
tic B or C, max. 10 A rated current,
min. 6 kA interrupting rating,
energy limiting class 3).
The device has not been designed
to support safety disconnection.
Please take the technical data (in
particular the maximum permissi-
ble switching capacity of the load
circuits and the type of load to be
connected) into account before
connecting a load. Do not exceed
the capacity specified for the de-
vice.
Do not connect three-phase mo-
tors.
Only shutters and blinds with limit
switches (mechanical or electro-
nic) should be used. Before put-
ting the actuator into operation,
check that the limit switches on
the connected motors have been
adjusted correctly.
The device may only be operated
within domestic environment, in
business and trade areas as well as
in small enterprises.
If you use the device/system in a
security application it has to be
operated in connection with an
UPS (uninterruptible power sup-
ply) in order to bridge possible
power failure.
Using the device for any purpose
other than that described in this
operating manual does not fall
within the scope of intended use
and shall invalidate any warranty
or liability.
