17
CONTROLS AND FEATURES
THROTTLE GRIP
INCREASE
THROTTLE INDEX MARK
Throttle Grip
The switch clip must be inserted in
the engine stop switch in order for
the engine to start and run. The
lanyard should be attached to the
operator’s PFD (Personal Flotation
Device) or worn around the wrist as
shown.
When used as described, the
emergency stop switch and lanyard
system stops the engine if the
operator falls away from the controls.
The throttle grip controls engine
speed.
An index mark on the tiller arm
shows throttle position and is helpful
for setting the throttle correctly when
starting (p. ).
A spare switch clip is supplied with
the motor (LH and LHT types).
38
