26
INSTRUMENTS
Trim Meter
Tachometer Fuel Gauge
(optional equipment)
[optional equipment (LHT,
LRT and XRT Types)]
[optional equipment (LHT,
LRT and XRT Types)]
CONTROLS AND FEATURES
TRIM METER
FUEL GAUGE
TACHOMETER
The tachometer shows engine speed
in revolutions per minute.
Refer to the tachometer when using
the throttle and power trim/tilt
controls to achieve the best
performance from the boat.
A fuel gauge is built into the cap of
the portable fuel tank (optional
equipment).
The trim meter indicates the relative
trim angle of the outboard motor.
Refer to the trim meter when using
the power trim/tilt switch to achieve
proper boat performance.
05/02/22 10:49:02 31ZW3600_027
