Gasoline is highly
flammable and explosive.
You can be burned or
seriously injured when
handling fuel.
Stop the engine and keep
heat, sparks, and flame
away.
Handle fuel only
outdoors.
Wipe up spills
immediately.
26
PORTABLE FUEL TANK FUEL HOSE CONNECTIONS
OPERATION
(OUTBOARD MOTOR SIDE)
FUEL HOSE CONNECTOR
FUEL HOSE CONNECTOR
(FUEL TANK SIDE)
FUEL HOSE
(standard equipment)
Secure the portable fuel tank in the
boat so that it won’t move around
and become damaged. Turn the portable fuel tank vent knob
counterclockwise to the open
position.
To ensure that the outboard motor
will be able to draw fuel from the
tank, place the tank within 6 feet (2
m) of the outboard motor and not
more than 3 feet (1 m) below the fuel
connector on the outboard motor.
Place the portable fuel tank in a well-
ventilated location, away from direct
sunlight, to reduce the possibility of a
gasoline vapor explosion.
