30
EMERGENCY STARTING
OPERATION
EMERGENCY STARTER ROPE
6 mm CAP NUTS
FLYWHEEL COVER
6 mm FLANGE
BOLTS
UNLOCK
ENGINE COVER LOCK LEVER
Pull the emergency starter rope
slowly until resistance is felt, then
pull briskly.
Keep away from moving parts
while pulling the rope.
If the recoil starter is inoperative, you
can start the engine manually using
the emergency starter rope supplied
with the tool kit.
Unlock and remove the engine
cover.
Remove the two 6 mm cap nuts
and 6 mm flange bolts, and
remove the flywheel cover.
Set the controls the same as for
normal starting (see pages
). Use the choke control if
needed.
Set the knotted end of the
emergency starter rope in the notch
in the flywheel. Wind the rope
clockwise around the flywheel.
2.
3.
4.
5.
1.
27
28
