37
MOORING, BEACHING,
LAUNCHING
OPERATION
38°, 58° (when mooring)
ENGINE COVER GRIP
TILT LEVER
To return the outboard motor to the
normal operating position, raise the
outboard slightly by pulling on the
engine cover grip, then pull the tilt
lever to release the outboard, and
then slowly lower the outboard motor.
Before tilting up, leave the outboard
motor in the running position for one
minute after stopping the engine to
drain the water from inside the
engine.
To raise the outboard motor out of
the water while the boat is moored, or
for maximum clearance when
beaching or launching, tilt the
outboard motor to the 38° or 58°
position.
Raise and lower the outboard motor
as described on p. .
Stop the engine before tilting the
outboard motor. The 38° or 58°
position is not an operating position.
Stop the engine and disconnect the
fuel hose from the outboard motor
before tilting the outboard motor.
36
