0.11 US qt (0.10 L)
4.8 lbf·ft (6.5 N·m, 0.66 kgf·m)
4.8 lbf·ft (6.5 N·m, 0.66 kgf·m)
47
SERVICING YOUR OUTBOARD MOTOR
GEAR OIL BOTTLE
GEAR OIL CAPACITY:
OIL LEVEL SCREW TORQUE:
OIL DRAIN SCREW TORQUE:
Add oil through the oil drain hole
until it flows out the oil level hole,
and then install the oil level screw.
Remove the pump adapter and
install the oil drain/fill screw.
Avoid losing more than 1 fl oz (30
cm ) while reinstalling the drain/
fill screw.
Outboard motor SAE 90 hypoid
gear oil API Service category
(GL-4)
3.
3
11/03/07 16:34:59 31ZV1660_048
