15
CONTROLS
Fuel Valve Lever (BF4A)
The fuel valve opens and closes the
passage between the internal fuel tank
and the carburetor.
The fuel valve lever must be in the
ON position for the engine to run.
When the engine is not in use, leave the
fuel valve lever in the OFF position to
prevent carburetor flooding and to
reduce the possibility of fuel leakage.
(BF5D and BF6A)
The fuel valve lever has internal fuel tank
position and portable fuel tank position.
When using the internal fuel tank,
turn the fuel valve lever to the
internal fuel tank position.
When not connecting the portable
fuel tank, fuel is shut off at the
portable fuel tank position.
When using the portable fuel tank,
turn the fuel valve lever all the way to
the portable fuel tank position.
ON (BF4A) or
INTERNAL FUEL TANK POSITION
OFF (BF4A) or PORTABLE
FUEL TANK POSITION
(BF5D and BF6A)
FUEL
VA LV E
LEVER
(BF4A)
(BF5D and BF6A)
ON
OFF
INTERNAL FUEL
TANK POSITION
PORTABLE
FUEL TANK
POSITION
