16
CONTROLS
(BF4A):
(BF5D and BF6A):
LEVER POSITION FUNCTION
ON
Fuel from the internal fuel tank is
supplied.
OFF
Fuel supply is shut off.
Set the fuel valve lever to the “OFF”
position during transporting or storing the
outboard motor.
LEVER POSITION FUNCTION
INTERNAL
FUEL TANK
Fuel from the internal fuel tank is
supplied.
PORTABLE
FUEL TANK
• Fuel from the portable fuel tank is
supplied.
• If the portable fuel tank is not
connected, fuel supply is shut off.
Set the fuel valve lever to the
“PORTABLE FUEL TANK” position
during transporting or storing the
outboard motor.
Handle Stopper
The tiller handle can be moved to the
bottom direction by turning the
handle stopper.
HANDLE
STOPPER
TILLER
HANDLE
32ZVC6000.book Page 16 Thursday, April 28, 2016 10:51 AM
