SPECIFICATIONS
*1 With propeller
*2 SHND, SHNU, LHND, and LHNU types are Optional
Equipment
*3 For U types
*4 For D types
MODEL BF5D
Description
Code
BADC
Type SHD SHU
SHND SHNU
LHD LHU
LHND LHNU
Overall length 524 mm (20.6 in)
Overall width 347 mm (13.7 in)
Overall height 1,020 mm (40.2 in) 1,147 mm (45.2 in)
Transom height
(when transom
angle at 12°)
434 mm (17.1 in) 561 mm (22.1 in)
Dry mass
(weight) *1
27.8 kg
(61.3bs)
27 kg
(60 lbs)
28.3 kg
(62.4 lbs)
27.5 kg
(60.6 lbs)
Rated power
3.68 kW (5 PS)*3
3.7 kW (5 PS)*4
Full throttle
range
4,500 – 5,500 min
-1
(rpm)
Engine type 4-stroke, single cylinder, OHV type
Displacement
127 cm
3
(7.7 cu-in)
Spark plug gap 0.6 – 0.7 mm (0.024 – 0.028 in)
Starter system Recoil starter
Ignition system C.D.I.
Lubrication
system
Trochoid pump pressure lubrication
Specified oil Engine: API standard (SG, SH, SJ) SAE 10W-30
Gear case: API standard (GL-4) SAE 90
Hypoid gear oil
Oil capacity Engine: 0.55 L (0.58 US qt, 0.48 Imp qt)
Gear case: 0.10 L (0.11 US qt, 0.09 Imp qt)
D.C. output *2 12V – 6A
Cooling system Water cooling with thermostat
Exhaust system Underwater exhaust
Spark plug BKR6E-E (NGK)
Fuel pump Mechanical type
Fuel Unleaded gasoline
(91 research octane, 86 pump octane or higher)
Tank capacity Internal fuel tank: 1.5 L (0.40 US gal, 0.33 Imp gal)
Portable fuel tank: 12 L (3.2 US gal, 2.6 Imp gal)
Gear change Forward – Neutral – Reverse (dog type)
Steering
equipment
Bar handle
Steering angle 45° (right and left)
Transom angle 5 stages (4°, 8°, 12°, 16°, 20°)
Tilt up angle
(when transom
angle at 12°)
3 stages adjustment (18°, 34° and 58°)
Standard
propeller
(No. of blades –
diameter ×
pitch)
3 – 200 × 170 mm (3 – 7-7/8 × 6-3/4 in)*3
3 – 200 × 190 mm (3 – 7-7/8 × 7-1/2 in)*4
Honda outboards are power rated in accordance with ISO8665 (propeller shaft output).
