(4)
(2)
(1)
LEFT SIDE
LEFT SIDE
(1) screws (2) air cleaner
housing cover
(3)
(3) screws
(4) air cleaner
(1)
108
Replacement
Air Cleaner
Servicing Your Honda
Remove the six screws (1) that secure
the air cleaner housing cover (2).
Remove the two screws (3) that secure
the air cleaner (4).
Discard the air cleaner.
Install a new air cleaner.
Install the removed parts in reverse
order of removal.
1.
3.
4.
5.
2.
